ASTM 합금 강철 급료 Inconel 배관, 장력 재산 Inconel 좋은 625 관

기본 특성
원산지: 중국
브랜드 이름: Torich
인증: CE PED
모델 번호: Inconel 625
부동산 거래
최소 주문 수량: 1000kg
가격: 6000-20000 USD per ton
지불 조건: L / C, T / T
공급 능력: 년 당 200 톤
제품 요약
인코넬 스틸 튜브는 합금 스틸 등급 인코넬 625으로 생산됩니다. 화학 성분:% 최대 C:≤0.10 Cr:20.0-23.0 Co:≤1.00 Mo:8.0-10.0 Al:≤0.40 Ti:≤0.40 Nb:3.15-4.15 Fe:≤5.00 Mn:≤0.50 Si:≤050 P:≤0015 S: ≤0.015 Cu:≤0.07 물리적 변수: 밀도1kg/cu 0.305g/cc 8.44 소재의 특성: 경식 저항성 우수 산화 저항성 크리오겐성에서 980°C까지 튼튼한 팽창성 냉동에서 980°C까지 좋은 피로 성질 인코넬 625기계적 특성 종류 팽창성 특성 ...

제품 상세정보

강조하다:

Inconel 600 관

,

inconel 718 관

Material: 625
Standard: ASTM B444
OD: 1-450mm
Production Method: 비긴 냉기
Type: 원활한
MTC: En10204.3.2B
제품 설명

인코넬 스틸 튜브는 합금 스틸 등급 인코넬 625으로 생산됩니다.

화학 성분:% 최대

C:≤0.10 Cr:20.0-23.0 Co:≤1.00 Mo:8.0-10.0 Al:≤0.40 Ti:≤0.40 Nb:3.15-4.15

Fe:≤5.00 Mn:≤0.50 Si:≤050 P:≤0015 S: ≤0.015 Cu:≤0.07

물리적 변수:

밀도1kg/cu 0.305g/cc 8.44

소재의 특성:

경식 저항성 우수

산화 저항성

크리오겐성에서 980°C까지 튼튼한 팽창성

냉동에서 980°C까지 좋은 피로 성질

인코넬 625기계적 특성

종류 팽창성 특성 지속적 성능 단단함
θ/°C σb/MPa σP0.2/MPa δ5/% θ/°C σ/MPa t/h δ5/%
보다 큰 보다 큰
타 1 20 830 410 30 815 114 23 15 HB≤290
2페이지 20 830 410 30 815 114 23 15 HV≤305
20 830 410 30 Q/3B 4078-1992 -
20 825 415 30 Q/3B 4077-1992 -
파이프 20 825 415 35 Q/3B 4080-1992 HRC≤25

1 표준 Z9-0105-1990. 2 표준 Z9-0104-1990 및 GJB 3317-1998.

표준:

튜브 표준: ASTM B444 니켈-크롬-몰리브덴-콜럼비아 합금 (UNS N06625 및 UNS N06852) 및 니켈-크롬-몰리브덴-실리콘 합금 (UNS N06219) 파이프 및 튜브

ASTM B622 꿰매지 않는 니켈 및 니켈-코발트 합금 파이프 및 튜브

판 및 스트립 표준:ASTM B443 니켈-크롬-몰리브덴-콜롬비아 합금(UNS N06625 및 UNS N06852)) 및 니켈-크롬-몰리브덴-실리콘 합금 (UNS N062191) 판,판,줄

도조: ASTM B564 니켈 합금 도조.

항공기 엔진 부품,해수 용도,엔진 배기 시스템,연료 및 수압 선 파이프에 적용됩니다.
