EN10216 - 2 & DIN17175 Boiler and Pressure System Seamless Steel Tubes Description: Appilcations for manufacturing pipelines of boilers, vessel quipment Outside Diameter 5 - 420mm Wall Thickness 0.5 - 50mm Length Max12000mm Steel, Chemical Composition & EN10216-2: Grade C Si Mn P S Cr Mo 195GH ≤0.13 ≤0.35 ≤0.70 ≤0.025 ≤0.020 ≤0.30 ≤0.08 P235GH ≤0.16 ≤0.35 ≤1.20 ≤0.025 ≤0.020 ≤0.30 ≤0.08 P265GH ≤0.20 ≤0.40 ≤1.40 ≤0.025 ≤0.020 ≤0.30 ≤0.08 20MnNb6 ≤0.22 0.15-0.35 1.00-1.50 ≤0

EN10216-2& DIN17175 Seamless Steel Tubes For Pressure Purposes-Technical Delivery Conditions Applications: For manufacturing pipelines of boilers Vessel equipment Size range: O.D. 5-420mm W.T. 0.5-50mm Length max12000mm Steel Grade, Chemical Compositions and Mechanical Property: Standard Grade Chemical Compostion Mechanical Property C Si Mn P S Cr Mo Mpa Mpa L T EN10216-2 195GH ≤0.13 ≤0.35 ≤0.70 ≤0.025 ≤0.020 ≤0.30 ≤0.08 320-440 ≥195 ≥27 ≥25 P235GH ≤0.16 ≤0.35 ≤1.20 ≤0.025 ≤0

17mm High Precision Seamless Steel Tube 17mm High Precision Seamless Steel Tube 1.Quick Detail: Black Phosphated Hydraulic Tubes with High Precision EN10305-1, EN10305-4, DIN2391, E235, E355, ST37.0, ST44.0, ST52.0 Steel Pipes with high precision for Hydraulic Systems Black Phosphating 2.Production process: DIN series tubes, cold drawn and bright annealed precision seamless steel tube is used as the tube to be phosphated. The phosphorization is realized with the imported

Torich 210mm OD EN10305-4 Precision Carbon Steel Tube Seamless Carbon Steel Pipe Brief introduction: Product name 210mm OD EN10305-4 Precision Carbon Steel Tube Seamless Carbon Steel Pipe Standard EN10305-2, EN10305-4,JIS-G3445,DIN2393 Size OD:5-210mm WT:1-25mm Usage Gas Spring,Automobile Shock Absorber Cylinder,Motorcycle Front Fork,Automobile Shock Absorber Reservior. Shape Round Type Seamless Manufacture Cold drawn Packing Usually bundles in cartons The tubes shall be

Torich 12m Length 415mpa 45# High Precision Tube DIN 2440 St33 Seamless Steel Tubes Introduction: Product name: Torich DIN 2440 St33 Tubo Seamless Steel Tubes Carbon Pipes Standard: DIN 2440 Technical: Hot rolled Size Range: OD: 6-1016mm WT: 2.87-150mm Length:5-12m Application: Mechanical industry, construction,etc Section shape: Round Surface tratement Black/no coating Application: Hot rolled structural tube, fluid tube, medium and low boiler Material: 10 # 20 # 45#

Torich 210mm OD EN10305-4 Precision Carbon Steel Tube Seamless Steel Pipe Brief introduction: Product name 210mm OD EN10305-4 Precision Carbon Steel Tube Seamless Steel Pipe Standard EN10305-2, EN10305-4,JIS-G3445,DIN2393 Size OD:5-210mm WT:1-25mm Usage Construction, Automobile,etc Shape Round Type Seamless Manufacture Cold drawn Packing Usually bundles in cartons The tubes shall be manufactured from hot finished seamless hollows by cold drawing. The tubes shall be delivered

DIN2391 ST 37.4 nbk Boiler Tube Specification Offered For DIN 2391 st37.4 fuel injection steel tube Standard: DIN 2391 Steel grade: ST35, ST37, ST37.4, ST45, ST52, ST52.4 Size: OD (4-190mm) x WT (0.5-15mm) Delivery condition: NBK(+N), GBK(+A), BK(+C), BKW(+LC), BKS(+SR). Application: Used in hydraulic system, automobile, locomotive and military industry. Chemical Composition Grade Chemical Composition(%): C max Si max Mn P max S max St 35 0.17 0.35 ≥0.40 0.025 0.025 St 45 0

Products Description: EN10216-2 Steam Boiler Tubes for Pressure Vessels and Heat Exchanger Tubes EN10216-2 is specification made for seamless steel tubes for specified elevated temperature purposes as boiler tube, power plants, etc, it has following steel grades: P195GH, P235GH, P265GH, 16Mo3, 14MoV6-3, 13CrMo4-5, 10CrMo9-10, with non-alloy and alloy steel included. EN 10216-2 specifies the technical delivery conditions in 2 test categories for seamless tubes of circular

Products Description TORICH ASTM A105 Grade B Seamless Carbon Steel Pipe Tube Material 10# 20# SAE1010, SAE1020, SAE1026, SAE4130, SAE4140 Size WT: 1-25mm; OD: 50-350mm; Length: max 12m Production Method Seamless Cold Drawing Or Cold Rolling End protector Plain End / Beveled End Test Tension Test, Flaring Test, Flange Test, Reverse Test, Hardness Test, Hydrostatic or Nondestructive Electric Test Sizing method: Thermal Treatment: 1) HF-Hot finished 1) A-Annealed 2) CW-Cold
