열교환기 관

ASTM B111 C68700 Aluminum Brass Seamless Tube for Condensers and Heat-exchangers Type: Copper Steel Tube Application: For surface condenser, heat exchanger, and evaporators Technique: Cold Drawn Size: OD 5-420mm WT 1-50mm LENGTH Max12000mm Chemical Composition: Chemical Composition Elements Composition, % Cu, incl. Ag 76.0-79.0 Sn – Al 1.8-2.5 Ni, incl. Co – Pb 0.07 max Fe 0.06 max Zn Balance Mn 0.02-0.06 Mechanical Proporties: Copper or Copper Alloy UNS No. Temper Designatio

JIS G3463 Seamless and welded stainless steel tube for boiler tube and heat-exchanger Type: Seamless and welded stianless steel pipes Application: For chemical and petroleum industries Technique: Cold-finished, hot-finished, ERW Size: OD 5-420mm WT 1-50mm LENGTH max12000mm Product Description Chemical Composition: Grade Chemical composition % C Si Mn P S Ni Cr Mo SUS 304TB 0.08 max. 1.00 max. 2.00max. 0.040 max. 0.030 max. 8.00~11.00 18.00~20.00 - SUS 304HTB 0.04~0.10 0.75

JIS G3462 Seamless and welded Alloy steel tube for boiler tube and heat-exchanger Type: Seamless and welded alloy steel pipes Application: For water tubes, smoke tubes, superheater tubes, heat-exchanger Technique: Cold-finished, hot-finished, ERW Size: OD 15.9-135.8mm WT 0.5-50mm LENGTH max12000mm Product Description Chemical Composition: Grade Chemical Composition % C Mn P S Si Cr Mo STBA12 0.10-0.20 0.30-0.80 ≤0.035 ≤0.035 0.10-0.50 … 0.45-0.65 STBA13 0.15-0.25 0.30-0.80 ≤0

JIS G3461 Carbon Steel Tubes for Boiler and Heat Exchanger Type: Seamless and welded carbon steel pipes Application: For boiler pipe, smoke pipe, heat-exchanger and chemical industry Technique: Cold-finished, hot-finished, ERW Chemical Composition: Grade Process Chemical Composition (%) C Si Mn P S Ni Cr Mo Others STB35 S, E 0.18Max 0.35Max 0.30~0.60 0.035Max 0.035Max - - - - STB42 S, E 0.32Max 0.35Max 0.30~0.60 0.035Max 0.035Max - - - - STB52 S, E 0.25Max 0.35Max 1.00~1.50 0

JIS G3466 Carbon Steel Square and Rectangular Tubes JIS G3466 Carbon Steel Square pipe is used for civil engineering architecture and other structure buidings. Manufacture method can be forming welded steel pipes(electric resistance welding. forging welding or automatic arc welding) or seamless pipes into shape of square section. JIS G3466 Carbon Steel Square pipe shall be manufactured with no heat treated method. Chemical Composition: Designation of grade Chemical Compositio

JIS G3463 Carbon Steel Tubes for Boiler and Heat Exchanger JIS G3463 specifies the stainless steel tubes used for exchanging heat on the inside and outside of the tube, it has similar application as JIS G3461 and JIS G3462, while it has better corrosion resistant ability suitable for chemical and petroleum industries. However, it is not applicable to the heating furnace tube. Tube and pipe products of this specification covers more than 10 steel grades from SUS304TB to SUS

JIS G3461 Seamless and welded carbon steel pipes for boiler pipe and heat-exchanger Type: Seamless and welded carbon steel pipes Application: For boiler pipe, smoke pipe, heat-exchanger and chemical industry Technique: Cold-finished, hot-finished, ERW Product Description Chemical Composition: Grade Process Chemical Composition (%) C Si Mn P S Ni Cr Mo Others STB340 S, E 0.18Max 0.35Max 0.30~0.60 0.035Max 0.035Max - - - - STB410 S, E 0.32Max 0.35Max 0.30~0.60 0.035Max 0.035Max

JIS G3461 Carbon Steel Tubes for Boiler and Heat Exchanger Scope:JIS G3461 Carbon Steel Tubes is mainly used for exchanging heat on the inside and outside of the tube, such as water tubes, smoke tubes, superheater tubes, air preheater tubes, etc.Its application fields are: boiler tubes, heat exchanger tubes, condenser tubes, catalyzer tubes, etc. It can also be used in chemical and petroleum industries, But it can't be used for low temperature service. Chemical Composition:

JIS G3462 ALLOY STEEL BOILER AND HEAT EXCHANGER TUBES JIS Specification alloy steel Tubes are used for high temperature service applications. Seamless Alloy Steel Tubes according to JIS G3462 Grade STBA 12 are reheated and furnished in full annlealed,isothermal annealed or normalised quenched and tempered condition. JIS G3462 Grade STBA 12 Alloy Steel Seamless Tubes have a typical chemistry with additions of 0.45-0.65 Molybdenum.Bearing minimum tensile strength of 380 Mpa JIS
