주문 구조상 합금 강관 38CrMoAl ISO 41CrAlMo74 GB/T3077
기본 특성
원산지:
중국
브랜드 이름:
Torich
인증:
ISO 9001:2008 , TS16949
모델 번호:
합금 강철 38CrMoAl ISO 41CrAlMo74
부동산 거래
최소 주문 수량:
5mt
가격:
협상 가능
지불 조건:
L / C, T / T
공급 능력:
6000MT/month
제품 요약
합금 강철 파이프 등급 GB/T3077 38CrMoAl ISO 41CrAlMo74 구조 강철 파이프 표준 GB/T3077: 38CrMoAl ISO: 41CrAlMo74 GOST: 38X2M오A(38XM오A) DIN: 41CrAlMo7 34CrAlMo5 BS 905M39 905M31 NF: 40CAD6.12 30CAD6.12 화학적 성분:C:0.35~0.42시:0.20~0.45원자:00.30~0.60S:≤0.035P:≤0.035C:1.35~1.65Ni: ≤ 0.030Cu: ≤ 0.030모:00.15~0.25 팽창 강도:σb (MPa)...
제품 상세정보
강조하다:
합금 강철 관
,원활한 합금 강관
Product Name::
합금 강철 관
Grade::
GB/T3077, 38CrMoAl, ISO41CrAlMo74
Material:
합금강
Production:
끝나는 뜨거운 완성되는 및 감기
제품 설명
합금 강철 파이프 등급 GB/T3077 38CrMoAl ISO 41CrAlMo74 구조 강철 파이프 표준
GB/T3077: 38CrMoAl
ISO: 41CrAlMo74
GOST: 38X2M오A(38XM오A)
DIN: 41CrAlMo7 34CrAlMo5
BS 905M39 905M31
NF: 40CAD6.12 30CAD6.12
화학적 성분:
C:0.35~0.42
시:0.20~0.45
원자:00.30~0.60
S:≤0.035
P:≤0.035
C:1.35~1.65
Ni: ≤ 0.030
Cu: ≤ 0.030
모:00.15~0.25
팽창 강도:σb (MPa):≥980(100)
강도:σs (MPa):≥835(85)
길쭉함:δ5 (%):≥14
ψ (%):≥50
영향력:Akv (J):≥71
αkv (J/cm2):≥88(9)
ISO: 41CrAlMo74
GOST: 38X2M오A(38XM오A)
DIN: 41CrAlMo7 34CrAlMo5
BS 905M39 905M31
NF: 40CAD6.12 30CAD6.12
화학적 성분:
C:0.35~0.42
시:0.20~0.45
원자:00.30~0.60
S:≤0.035
P:≤0.035
C:1.35~1.65
Ni: ≤ 0.030
Cu: ≤ 0.030
모:00.15~0.25
팽창 강도:σb (MPa):≥980(100)
강도:σs (MPa):≥835(85)
길쭉함:δ5 (%):≥14
ψ (%):≥50
영향력:Akv (J):≥71
αkv (J/cm2):≥88(9)
단단함≤ 229HB: 30mm
